Beschrijving
Beheerfuncties
Switch type
Managed
Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten
16
Type basis-switching RJ-45 Ethernet-poorten
12x 1 Gbit/s
4x 2.5 Gbit/s
4x 2.5 Gbit/s
Aantal SFP+ poorten
2
Snelheid SFP+ poorten
10 Gbit/s
Data-uitwisseling
Switchingcapaciteit
84 Gbit/s
Throughput
42 Gbit/s
Packet forwarding rate (10 Mbps)
62.496 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Ja
Aantal Power over Ethernet plus (PoE +)-poorten
12
Voltagebereik Power over Ethernet (PoE)
44-57V DC
Vermogen per poort Power over Ethernet (PoE)
PoE: 15.4W
PoE+: 30W
PoE++: 60W
PoE+: 30W
PoE++: 60W
Totaal Power over Ethernet (PoE)-budget
180 W
Aantal Power over Ethernet (PoE ++)-poorten
4
Gewicht en omvang
Breedte
325,1 mm
Diepte
160 mm
Hoogte
43,7 mm
Netwerk
Maximale snelheid
2500 Mbit/s
Design
Display
1.3" Touchscreen
Etherlighting™
Etherlighting-poorten die oplichten om de poortlocatie, snelheid/link en native VLAN/netwerk aan te geven
Geadvanceerde functies
Level 2 functies
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control 802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC Device isolation with ACLs
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control 802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC Device isolation with ACLs
