Beschrijving
Beheerfuncties
Switch type
Managed
Quality of Service (QoS)
Port-based/802.1p/DSCP QoS
8 Priority Queues
Priority Schedule Mode – WRR (Weighted Round Robin)
Queue Weight Config
Bandwidth Control – Port-Based Rating Limit
Storm Control – Multiple Control Modes (kbps/pps) – Broadcast/Multicast/Unknown-Unicast Control?
8 Priority Queues
Priority Schedule Mode – WRR (Weighted Round Robin)
Queue Weight Config
Bandwidth Control – Port-Based Rating Limit
Storm Control – Multiple Control Modes (kbps/pps) – Broadcast/Multicast/Unknown-Unicast Control?
Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten
8
Aantal SFP+ poorten
1
Snelheid SFP+ poorten
10 Gbit/s
Aantal 10 Gbit RJ-45 Poorten
1
Netwerk
10G support
Ja
Virtuele LAN-functies
MTU VLAN
Port-Based VLAN
802.1Q Tag VLAN
Max 32 VLAN Groups
4K VID
Port-Based VLAN
802.1Q Tag VLAN
Max 32 VLAN Groups
4K VID
Ethernet LAN, data-overdrachtsnelheden
100, 1000, 2500 Mbit/s
L2 features
Link Aggregation, Static Link Aggregation, Up to 6 aggregation groups and up to 4 ports per group
Loop Prevention / Loopback Detection
Flow Control – 802.3x Flow Control
Mirroring – Port Mirroring – One-to-One – Many-to-One – Ingress/Egress/Both
Port Statistics – Port Mirror Status – Traffic Statistics
802.1ab LLDP
Loop Prevention / Loopback Detection
Flow Control – 802.3x Flow Control
Mirroring – Port Mirroring – One-to-One – Many-to-One – Ingress/Egress/Both
Port Statistics – Port Mirror Status – Traffic Statistics
802.1ab LLDP
Maximale snelheid
2500 Mbit/s
Data-uitwisseling
MAC-adrestabel
16 K
Switchingcapaciteit
80 Gbps
Jumbo frames
10 KB
Packet forwarding rate (10 Mbps)
59.52 Mpps
Packet buffergeheugen
5 Mbit
Multicast-functies
Multicast-ondersteuning
IGMP Snooping
IGMP v1/v2/v3 Snooping
Snel verlaten
IGMP v1/v2/v3 Snooping
Snel verlaten
Design
Rack-montage
Nee
Vormfactor
Bureaublad-/wandmontage
Kleur van het product
Zwart
Prestatie
Fanloos
Ja
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Ja
Vermogen per poort Power over Ethernet (PoE)
90 W
Totaal Power over Ethernet (PoE)-budget
250 W
Aantal Power over Ethernet (PoE ++)-poorten
8
Gewicht en omvang
Breedte
226 mm
Diepte
131,2 mm
Hoogte
35 mm
